SEPDISP66
Back to product Seleziona lingua: · SEPDISP66V4 · SEPDISP66V12 · SEPDISP66V13 Installation instructions for Fiat 500, Abarth 500, 595, 695 instrument cluster LCD display Before installing the new display, please read the following instructions carefully.DO NOT SKIP ANY STEPS. Download printable PDF ATTENTION: THESE INSTRUCTIONS ARE VALID ONLY FOR SEPDISP66V4, SEPDISP66V12 AND SEPDISP66V13 DISPLAYS 1 Disassemble the instrument cluster and remove the faulty display. 2 Place the white backlight diffuser supplied with the Minitools display, underneath the orange one. 3 Install the Minitools display.
SEI-DISP259
Back to product Seleziona lingua: SEI-DISP259 Modification instructions for 7’’ UConnect modules produced in Europe For illustrative purposes only, our technicians made a video tutorial on how to carry out the modification to the display SEI-DISP259.DO NOT SKIP ANY STEPS. Watch the video tutorial Download printable PDF ATTENTION: DO NOT FOLLOW THESE MODIFICATION INSTRUCTIONS IF THE MODULE IS ASSEMBLED IN MEXICO 1 Undo the screws of the metal frame with a Torx T10 screwdriver. 2 With the aid of a pry tool, undo the display FPCs from the ZIF connectors. 3 Detach the PCB antenna from the plastic frame using a pry tool. 4 ON THE LOWER SIDE OF THE DISPLAY HOUSING: With a file, remove the plastic portions highlighted. 5 ON THE LATERAL SIDES OF THE DISPLAY HOUSING: File down on both sides the plastic portions highlighted by about 1 mm. 6 Remove the adhesive from the PCB antenna. 7 Replace the adhesive with the one supplied with the display. 8 Fix the PCB antenna as it was originally. 9 Place the metal frame and reconnect the FPCs. 10 To secure the frame, use the six screws supplied with the new display.THERE IS NO NEED TO TIGHTEN THE LOWER SIDE OF THE FRAME 11 After the modifications, the metal frame will properly fit into the plastic housing on all sides. Video Tutorial Modification for installing SEI-DISP259 on 7″ UConnect produced in Europe
SEPDISP87: Porsche 986 and 996 display modification
Back to product Seleziona lingua: SEPDISP87 Porsche 986 and 996 display modification WARNING: This process is recommended only to expert and qualified staff. Before installing the new SEPDISP87 display, please read the following instructions carefully.DO NOT SKIP ANY STEPS. Watch the video tutorial Download printable PDF THE FOLLOWING MODIFICATION IS NECESSARY FOR THE CORRECT FUNCTIONING OF SEPDISP87 DISPLAY. Replace the display in an ambient temperature of 25 °C. After replacing the display, switch on thecluster:GREEN CONNECTORpin n. 1 negativepin n. 17 negativepin n. 2 positivepin n. 18 positiveMeasure, then, the voltage between the points A and B indicated in picture 1. If the voltage measured is between12,7V and 12,9V, no modification is necessary; If the voltage detected is, instead, lowerthan 12,7V or higher than 12,9V, it isnecessary to do the modification described in the following paragraph “EEPROMMODIFICATION“. Pic. 1 Pic. 2 EEPROM MODIFICATION NOTE: For this modification it is necessary to use an EEPROM programmer. We recommend our SEP-EECLIP. PROCEDURE: • First, desolder the EEPROM shown in picture 2(93C86 or 93LC86) from the front side of the PCB.IMPORTANT: Make a backup of the de-soldered EEPROM, before the modification.• Set the programmer reading in 8 bit hexadecimal (HEX). • To reach a voltage close to 12,8V, it is necessary to modify the value of the location 02C6. Please note that increasing this location by 1 HEX unit, the variation will be +0,1V or vice versa. NOTE: If not familiar with hexadecimal calculation, it is possible to use the calculation tool in the box beside, simply typing in the values. VERIFICATION Once this modification has been done, measure again the voltage between the points A and B and check that it actually is between 12,7V and12,9V. If not, act on the location until the value is as close as possible to the correct range.
Porsche 996 and 986 instrument panel LCD screen identification
Back to product Seleziona lingua: Identify the displays for Porsche 911 996, Porsche Boxster 986 and Porsche Carrera GT instrument clusters: Select the model: Porsche 911 996 Porsche Boxster 986 Porsche Carrera GT Select the version for Porsche 911 996: versions from 1997 to 2002 Segments displays (e.g.) SEPDISP46A, SEPDISP46BV2, SEPDISP46B, SEPDISP46C, SEPDISPKIT-46A-B-C-V2, SEPDISPKIT-46A-B-C versions for 2002 to 2006 Dot-matrix display (e.g.) SEPDISP87 Select the version for Porsche Boxster 986: versions from 1996 to 2001 Segments displays (e.g.) SEPDISP46A, SEPDISP46BV2, SEPDISP46B, SEPDISP46C, SEPDISPKIT-46A-B-C-V2, SEPDISPKIT-46A-B-C versions from 2000 to 2004 Segments display (e.g.) SEPDISP88 versions from 2001 to 2004 Dot-matrix display (e.g.) SEPDISP87 Available displays for Porsche 911 996 instrument clusters Versions from 1997 to 2002 (segments displays) We recommend replacing all displays of the instrument panel, purchasing the kits, to avoid visualization differences between the new display and those not replaced. Attention!A good level of skill and soldering experience are required to replace the display. Installation instructions and video Versions from 2002 to 2006 (dot-matrix display) Attention!After replacing the display, you may need to optimise it by modifying the EEPROM parameters using a programmer Modification instructions Available displays for Porsche Boxster 986 instrument clusters Versions from 1996 to 2001 (segments displays) We recommend replacing all displays of the instrument panel, purchasing the kits, to avoid visualization differences between the new display and those not replaced. Attention!A good level of skill and soldering experience are required to replace the display. Installation instructions and video Versions from 2000 to 2004 (segments displays) We recommend replacing both sides displays of the instrument cluster, purchasing the kit SEPDISPKIT-91DX-91SX, to avoid visualization differences between the new display and that not replaced. Versions from 2001 to 2004 (dot-matrix display) Attention!After replacing the display, you may need to optimise it by modifying the EEPROM parameters using a programmer Modification instructions Scroll to top
SEPKEY02: Datasheet
Back to product Seleziona lingua: SEPKEY02 Datasheet cover kit for Toyota keys Download the printable PDF 1 Cover kit for toyota keys The SEPKEY02 kit includes 1 shell (front and rear part) and 8 pairs of adapters. The main advantage of this solution is that you can reuse the old key as, using the adapters, the shell is suitable to all kind of Toyota keys. Also, the kit can be used both for 2 button and 3 button keys. In the latter case the plastic block has be removed. 2 NOTE: Identify carefully the right pair of adapters for your key.
SEPDISP74A, SEPDISP74B: Installation instructions
Back to product Seleziona lingua: SEPDISP74 Installation instructions for side displays for Porsche 911 (997), Boxster (987), Cayman (987) and Ruf instrument panels Insert the backlight supplied with the Minitools spare part below the original one to avoid colour differences in the display. As an example, our technicians have made a video tutorial on how to repair the odometer. To watch it click here. WARNING! Repair should only be carried out by qualified and experienced personnel. Watch the video tutorial Download the printable PDF Supported car models: Porsche 911 (997), (2004 – 2012);Porsche Boxster (987), (2004 – 2012);Porsche Cayman (987), (2005 – 2013);RUF 3400 K, (2007);RUF R Kompressor, (2006 – 2009);RUF RGT, (2005 – 2011);RUF RGT-8, (2010);RUF RK Coupè, (2006 – 2007);RUF RK Spyder, (2005 – 2008);RUF Rt 12, (2004 – 2012);RUF Rt 12R, (2011 – 2012);RUF Rt 12S, (2012). 1 Remove the right and/or left frame and take the defective display off. WARNING: keep the conductive rubber strips of the display which will be re-used when re-assembling 2 Take the white original backlight off, fit the Minitools one and re-insert the white backlight over the new one. 3 Insert the new Minitools display, fit the metal frame and insert the conductive rubber strips in the slots placed on the rear part of the cluster when re-assembling. Video Tutorial How to replace Porsche 911 997, Boxster 987 and Cayman 987 instrument clusters faulty LCD display
SEPDISP50A, SEPDISP50B: Installation instructions
Back to product Seleziona lingua: SEPDISP50A – SEPDISP50B LCD Display Installation Instructions Before installing the new SEPDISP50A, SEPDISP50B display, please read the following instructions carefully. For illustrative purposes, our technicians have produced a video tutorial on how to carry out odometer repair. DO NOT SKIP ANY STEPS. Watch the video tutorial Download printable PDF 1 Open the instrument cluster and reach the motherboard as in picture. 2 Detach the flat of the original display from the motherboard using a hot air desoldering iron at under 180°C. Clean the contacts with a specific product (e.g. solvent). 3 You will notice that the contacts on the motherboard are covered with a graphite patina. The patina must be removed with a scraper in order to solder the FPC of the new display properly. 4 Clean the contacts again from the graphite residues. To facilitate soldering, it is advisable to use on the pins: first the flux, then a bit of solder and, finally, clean the contacts with a specific product (e.g. solvent). 5 Solder the FPC of the new display to the instrument cluster motherboard using solder wire and a soldering iron at 350°C. 6 Reassemble everything and test the instrument cluster by supplying power to the black connector: • pin no. 30: negative • pin no. 21 and no. 28: positive Video Tutorial How to repair Renault Twingo II dashboard with Minitools SEPDISP50B
Porsche 986 and 996 displays installation instructions
Back to product Seleziona lingua: Porsche 986 and 996 displays installation instructions These instructions are valid for the following displays: • SEPDISP46A • SEPDISP46B / SEPDISP46BV2 • SEPDISP46C • SEPDISPKIT-46A-B-C / SEPDISPKIT-46A-B-C-V2 Watch the video tutorial Download the printable PDF WARNING: THIS PROCESS IS RECOMMENDED ONLY TO EXPERT AND QUALIFIED STAFF Please read the following instructions carefully before installing the new displays; As an example, our technicians have made a video tutorial on how to carry out the installation. Video below. Do not leave out any steps. NOTE: It is highly recommended replacing the three displays even if not all of them have defects. This prevents display differences between the LCDs and the quality will be improved. 1 Open the instrument cluster and reach the motherboard. 2 Detach the flat of the original display from the motherboard by simply pulling it away. Clean the contacts with a specific product (e.g. solvent). 3 You will notice that the contacts on the motherboard are covered with a graphite patina. To perfectly solder the FPC of the new display, the patina has to be carefully removed with a scraper. Clean any residues with some solvent. 4 To properly solder the new display, add some solder wire on the contacts and remove any excess with the desoldering braid. 5 Solder the FPC pins on the board one at the time with a soldering iron with conical tip at 350°C. WARNING: using flux is not recommended to inesperienced staff, as misusing it may damage the board irreversibly. 6 NOTE: the same procedure has to be repeated for all displays to replace. Once all operations have been carried out, reassemble the instrument cluster. Video Tutorial Porsche 911 996 and Boxster 986 dashboards LCD displays replacement
SEPDISP45: Installation instructions
Back to product Seleziona lingua: SEPDISP45 Modification instructions Before installing the new SEPDISP45 display, please read the following instructions carefully. DO NOT SKIP ANY STEPS. Download printable PDF 1 Remove the original display. 2 Peel the adhesive film off the back as shown in the photo. 3 Apply the film to the back of the new Minitools display, making sure it adheres perfectly the SEPDISP45 display. 4 Once this operation is complete, insert the press-fit display into the dedicated connector on the main board. SEPDISP45 | VERS. 3.0
SEPDISP40: Modification instructions for Audi A4 B5 and A8 D2 display
Back to product Seleziona lingua: SEPDISP40 Modification instructions for Audi A4 B5 and A8 D2 display WARNING: THIS PROCESS IS RECOMMENDED ONLY TO EXPERT AND QUALIFIED STAFF Before installing the new SEPDISP40 display, please read the following instructions carefully. DO NOT SKIP ANY STEPS. Download the printable PDF Seal the flat cable of the new display on the PCB of the instrument cluster with a soldering iron with “T” tip at 350° C Pic. 1 Fit the display on its base and position the frame supplied with the kit as in picure 1. Lastly, overlap the original metal frame as in picture 2. Pic. 2
